CLUB3D CSV-1583 laptop dock/port replicator Wired Thunderbolt 4 Black

Key features

• Adopting Goshen Ridge solution
• Designed for TBT4™/USB4™ based PCs and compatible with TBT3™/DP-Alt-mode PCs
• Support Thunderbolt™ 4 max 40Gbps for high speed data and outstanding
• video transfer, compatible with TBT3™, USB4™, DP™Alt mode, USB protocol
• Among 3 streams, allow to output 2 streams at the same time and allow to
• output single 8K30Hz or dual 4K60Hz displays in Extended mode on Windows
• based system
• Among 2 videos (From DisplayLink®) allow to output dual 4K60Hz in Extended
• mode on both Mac (include M1, M2,M3) and Windows based systems
• Among all 7 video ports, allow to output max 3 videos when connected to M1
• M2,M3; 4 videos when connected to M1 Pro/Max, M2 Pro/Max, M3 Pro/Max
• and other Mac series and Windows NoteBooks
• RJ45 supports max 2.5G bandwidth
• USB ports support max 10G data transmission
• SD/TF supports SD4.0 with max 312MBps
• Self-powered from DC power adapter with max 96W for host, max 140W for host and Dock
• Support smart power which enables to flexibly distribute power to PC and Hub
• in real time according to the consumption of connected devices
• Compatibility Details:
• Support TBT4™/USB4™/TBT3™/DP-Alt-mode Hosts
• Support Windows 10 or upwards, Mac 13.5.2 (Limitations may vary on different
• Apple proprietary Silicon)
• Supports both the Kensington Anti-theft lock as well as the standard Nano
• Anti-theft lock(which uses Only 70% of the physical space)
