ATEN HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A) – photo 1
ATEN HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A) – photo 2
ATEN HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A) – photo 3
ATEN HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A) – photo 4
ATEN

ATEN HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)

R8,272
incl. VAT: R9,513
  • Stock: Backordered - ETA 7-10 Days
  • Brand: ATEN
  • Model: VE2812AT
  • EAN: 4719264649639
  • Product code: 1089520
Backordered goods Delivery in 7–10 working days

Available Options

R8,272 incl. VAT: R9,513

Key features

  • Extends HDMI or VGA signals over a single Cat 5e/6/6a cable
  • HDMI: 4K / 1080p at distance up to 100m via a Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
  • VGA: 1600 x 1200 and 1920 x 1200 up to 100m via a Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
  • Supports HDBaseT Long Reach Mode – up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p
  • Built-in PoH (Power over HDBaseT) function – the VE2812AT receives power supply from the HDBaseT output port on the connected device
  • Supports Auto Switch – allows the VE2812AT automatically switch to a newly plugged-in source

Key features

  • Extends HDMI or VGA signals over a single Cat 5e/6/6a cable
  • HDMI: 4K / 1080p at distance up to 100m via a Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
  • VGA: 1600 x 1200 and 1920 x 1200 up to 100m via a Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
  • Supports HDBaseT Long Reach Mode – up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p
  • Built-in PoH (Power over HDBaseT) function – the VE2812AT receives power supply from the HDBaseT output port on the connected device
  • Supports Auto Switch – allows the VE2812AT automatically switch to a newly plugged-in source
Tags: aten audio & video cables , aten audio & video cable

Description

ATEN VE2812AT is a transmitter for sending VGA (with audio) and HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. Featuring built-in PoH (Power over HDBaseT) function, the VE2812AT receives power supply from the HDBaseT output port on the connected device. This eliminates the need for a power adapter and reduces the hassle of power line deployment behind the wall. The VE2812AT guarantees reliable transmission of HDMI signals, supporting 3D, Deep Color, and embedded HD lossless audio formats. It also ensures transmission of VGA (with audio) at distance up to 100 m. In addition, it supports Long Reach Mode up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p.
1 x VE2812AT Transmitter
1 x RS-232 Terminal Block
4 x Foot Pads
1 x 0AD8-1F05-26M1 Power Adapter
1 x User Instructions

Price History

Price History

Current price8,272 ZAR
8,6868,2727,85809-2309-2910-0510-1210-1810-24
Regular price

Specifications

Features
Type AV transmitter
Maximum resolution 4096 x 2160 pixels
Maximum transfer distance 100 m
Bandwidth 10.2 Gbit/s
Bandwidth 340 MHz
HDCP Yes
Material Metal
3D Yes
Consumer Electronics Control (CEC) support Yes
HDCP version 2.2
Product colour Black
Ports & interfaces
Connectivity technology Wired
RJ-45 output ports 1
HDBaseT port Yes
VGA (D-Sub) input ports 1
HDMI in 1
Audio input 1
Remote (IR) output 1
DC-in jack Yes
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 60 °C
Operating relative humidity (H-H) 0 - 80%
Weight & dimensions
Width 123 mm
Depth 143.2 mm
Height 30 mm
Weight 640 g
Packaging data
Quantity per pack 1 pc(s)
Package width 59 mm
Package depth 239 mm
Package height 160 mm
Package weight 765 g
Logistics data
Master (outer) case width 250 mm
Master (outer) case length 325 mm
Master (outer) case height 175 mm
Master (outer) case gross weight 4.4 kg
Master (outer) case net weight 3.2 kg
Products per master (outer) case 5 pc(s)
