StarTech.com 24in Internal USB Motherboard Header to Serial RS232 Adapter - TAA – photo 1
Out of Stock / Please Enquire ETA
STARTECH

StarTech.com 24in Internal USB Motherboard Header to Serial RS232 Adapter - TAA

R737
incl. VAT: R848
  • Stock: Out of Stock / Please Enquire ETA
  • Brand: STARTECH
  • Model: ICUSB232INT1
  • Weight: 0.13 kg
  • Dimensions: 18 × 15 × 3 cm
  • EAN: 065030840934
  • Product code: 634138
Please Inquire
R737 incl. VAT: R848
We will email you when the product is back in stock.

Key features

  • USB Header to Straight-Through RS232 Serial
  • Supports COM port retention
  • Bus-Powered – no separate power supply or battery required
  • Single chip USB to asynchronous serial data transfer interface
  • UHCI/OHCI/EHCI host controller compatible
  • USB 2.0 Full Speed compatible
  • Synchronous and asynchronous bit bang interface options with RD# and WR# strobes
  • FIFO receive and transmit buffers for high data throughput.

Key features

  • USB Header to Straight-Through RS232 Serial
  • Supports COM port retention
  • Bus-Powered – no separate power supply or battery required
  • Single chip USB to asynchronous serial data transfer interface
  • UHCI/OHCI/EHCI host controller compatible
  • USB 2.0 Full Speed compatible
  • Synchronous and asynchronous bit bang interface options with RD# and WR# strobes
  • FIFO receive and transmit buffers for high data throughput.
Tags: startech cables , startech cable

Description

Add an RS232 serial port to any system with an available USB motherboard header

The ICUSB232INT1 USB to RS232 Serial Adapter lets you add an RS232 port to any desktop system that is equipped with an available USB motherboard header. Unlike standard USB to serial cables, this cable is designed for use inside the PC case, affording an entirely internal solution with no mess or extra adapters needed. This compact and simple USB adapter offers a cost-effective solution that bridges the compatibility gap between modern computers and legacy serial peripherals. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Price History

Price History

Current price754 ZAR
75475375108-2409-0409-1609-2710-0910-20
Regular price

Specifications

Ports & interfaces
Host interface IDC
Output interface Serial
Serial ports quantity 1
Serial interface type RS-232
Design
Internal Yes
Product colour Black, Green, Silver
Certification Microsoft WHQL, CE, FCC
Features
Chipset FTDI - FT232RL
Baud rate 115.2 Kbit/s
FIFO (First In, First Out) 256 B
Data bits 7, 8
Stop bits 1, 2
Operational conditions
Operating temperature (T-T) -10 - 85 °C
Storage temperature (T-T) -20 - 100 °C
Operating relative humidity (H-H) 5 - 85%
System requirements
Windows operating systems supported Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows CE, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Mac operating systems supported Mac OS X 13.0 Ventura
Server operating systems supported Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Weight & dimensions
Width 123 mm
Depth 45 mm
Height 12 mm
Weight 31 g
Packaging data
Mounting brackets included Yes
Drivers included Yes
Manual Yes
Package width 175 mm
Package depth 143 mm
Package height 33 mm
Package weight 160 g
Logistics data
Harmonized System (HS) code 84733020
Products per master (outer) case 75 pc(s)
Master (outer) case width 697 mm
Master (outer) case length 360 mm
Master (outer) case height 319 mm
