DETECTOR SMOKE FIRE TEMP./TSD-1 SATEL

The TSD-1 is a point detector designed to detect the early stages of a developing fire. For this purpose, it is equipped with a photoelectric sensor of visible smoke, as well as rate of rise temperature sensor. The unique design of the measuring chamber provides high sensitivity and omni-directionality, while a precise Hexamesh stainless steel filter protects the chamber from ingress of contamination and small insects. Detector configuration with DIP-switches and built-in parametric end of line resistors facilitate connection of the detector to virtually any control panel with a 12 V power supply.

• unique Swirl chamber for increased smoke sensitivity
• selectable operating mode (smoke, heat, multisensor)
• line type configuration (NO/NC/2EOL) with DIP switches
• precision stainless steel Hexamesh filter
• smoke chamber dirt build-up indicator
• easy installation with detachable base
• compatible with all 12 V alarm panels
• IP code: IP20

Summary: Satel TSD-1. Connectivity technology: Wired, Product colour: White, Best uses: Home, Office. Power source: DC, Input voltage: 12 V. Diameter: 10.8 cm, Height: 61 mm, Weight: 164 g. Quantity per pack: 1 pc(s) | Vendor Homepage: https://www.satel.pl/ | Best uses: Home,Office | Connectivity technology: Wired | Easy to install: Yes | Housing material: Plastic | LED indicators: Yes | Mounting type: Surface-mounted | Placement supported: Horizontal/Vertical | Product colour: White | Input voltage: 12 | Power source: DC | Operating relative humidity (H-H): 0 - 93 | Operating temperature (T-T): -10 - 55 | Diameter: 108 | Height: 61 | Weight: 164 | Quantity per pack: 1 | Product Net Weight: 0.164 | Shipping Box Height: 7 | Unit Calculated Volume: 0.001008 | Unit Calculated Weight: 0.2 | Units per Shipping Box: 1 | Model name: TSD-1
