StarTech.com 24 Port 1U Rackmount Cat 6 110 Patch Panel – photo 1
Out of Stock / Please Enquire ETA
STARTECH

StarTech.com 24 Port 1U Rackmount Cat 6 110 Patch Panel

R1,924
incl. VAT: R2,212
  • Stock: Out of Stock / Please Enquire ETA
  • Brand: STARTECH
  • Model: C6PANEL24
  • Weight: 0.68 kg
  • Dimensions: 50 × 6 × 6 cm
  • EAN: 065030857475
  • Product code: 634533
Please Inquire
R1,924 incl. VAT: R2,212
We will email you when the product is back in stock.

Key features

  • Color coded for both T568A and T568B installations
  • Terminated using 110-type punch tool
  • Supports both Cat5e and Cat6 cables
  • Writable and erasable marking surfaces for each port
  • Meeting the ANSI/TIA-568-C.2 Category 6, ISO/IEC11801 and EN50173-1 specification

Key features

  • Color coded for both T568A and T568B installations
  • Terminated using 110-type punch tool
  • Supports both Cat5e and Cat6 cables
  • Writable and erasable marking surfaces for each port
  • Meeting the ANSI/TIA-568-C.2 Category 6, ISO/IEC11801 and EN50173-1 specification
Tags: startech cable management , startech cable managemen

Description

Organize up to 24 Cat6 patch cables

The C6PANEL24 24-port 110-type Rack Mount Cat 6 Patch Panel is color coded for both T568A and T568B wiring providing the perfect solution for any voice or LAN application.

For hassle-free connections, the patch panel offers straight Cat 6 ports with 110-type termination, making it easy to insert and remove your cables. The 24-port patch panel also offers a quick and easy way to identify your cable runs, with port numbers clearly marked on the back of each RJ45 port, and a writeable/erasable marking surface for each port on the front of the panel for efficient system management.

Durably constructed of only top quality materials, this 24-port Network Patch Panel is backed by StarTech.com’s 2-year warranty.

Price History

Price History

Current price2,018 ZAR
2,0251,9891,95308-2409-0409-1609-2710-0910-20
Regular price

Specifications

Network
Ports quantity 24
Connector(s) RJ-45
Design
Mounting Rack mounting
Rack capacity 1U
Product colour Black
Certificates
Compliance certificates RoHS
Certification CE, ETl, UL
Operational conditions
Operating temperature (T-T) -10 - 60 °C
Operating relative humidity (H-H) 10 - 65%
Weight & dimensions
Width 483 mm
Height 34 mm
Depth 44 mm
Weight 581 g
Packaging data
Package width 491 mm
Package depth 59 mm
Package height 47 mm
Package weight 678 g
Logistics data
Harmonized System (HS) code 85371098
Master (outer) case width 516 mm
Master (outer) case length 255 mm
Master (outer) case height 268 mm
Products per master (outer) case 20 pc(s)
